Goslyn Grease Separation

A Goslyn is an Automatic Grease Removal Device (AGRD) meaning it operates without moving parts or chemicals and the primary function is to virtually eliminate fats, oils and grease (FOG) in wastewater effluent.

A hydraulic immiscible liquid separator designed to eject the retained FOG from within the main separation chamber on a constant “always on” basis. The FOG recovered has a low moisture content of less than 5%, which is widely acceptable for Bio-Diesel production.

There are no moving parts to break or maintain and no messy, time-consuming grease traps to clean. Plus… its small footprint makes it easy to install in even the smallest kitchens. Ideal for applications such as dishwashers, pre-rinse sinks, three-compartment sinks, woks, kettles, combi ovens and rotisserie ovens.

Seeing the remarkable Goslyn separator in action will provide you with a true sense of its compact “install anywhere” footprint, ingenious design and highly efficient operation.

Features & Benefits

Goslyn is an industry leader in grease removal with its line of sustainable and environmentally friendly automatic grease removal devices and related solutions. Its patented, high-efficiency, cost-effective automatic grease removal devices have a range of unique features and benefits that set it apart from other systems on the market.

  • No moving parts and less maintenance time
  • Small footprint for simple installation and retrofit
  • Made from strong, durable, lightweight and hygienic grade 304 stainless steel
  • Maintains a 96.4% grease removal efficiency, higher than other systems on the market
  • Unique system design allows for multiple discharging configurations
  • 5 year limited warranty
  • The Goslyn meets (and exceeds) the industry codes and standards including UL, IPC, UPC, IRC, NPC, ASME A112.14.3, ASME A1123.14.4, PDI G101, and CSA B481.1

GOS20

  • Length: 479 mm
  • Width: 292 mm
  • Height: 312 mm
  • Weight: 21.8 Kg
  • 15.1 LPM

GOS40

  • Length: 644 mm
  • Width: 406 mm
  • Height: 362 mm
  • Weight: 34.0 Kg
  • 37.9 LPM

GOS60

  • Length: 949 mm
  • Width: 406 mm
  • Height: 362 mm
  • Weight: 52.2 Kg
  • 56.8 LPM

GOS80

  • Length: 848 mm
  • Width: 406 mm
  • Height: 502 mm
  • Weight: 61.2 Kg
  • 94.6 LPM

GOS80LP

  • Length: 1052 mm
  • Width: 610 mm
  • Height: 364 mm
  • Weight: 67.1 Kg
  • 94.6 LPM
  • Low profile body

GOS160

  • Length: 959 mm
  • Width: 600 mm
  • Height: 558 mm
  • Weight: 99.8 Kg
  • 189.3 litres per minute

GOS320

  • Length: 1274 mm
  • Width: 602 mm
  • Height: 888 mm
  • Weight: 117.9 Kg
  • 378.5 LPM
